Specifications
- Physical dimensions (LxWxH): 16.54" x 8.27" x 2.24" (420 x 210 x 57 mm)
- Amplifier class: D
- Peak power (Watts): 2000 W
- Total rated power output - 4 Ohm (Watts): 100 W RMS x 8 @ 14.4 V input - 4 Ohm < 1% THD
- Total rated power output - 2 Ohm (Watts): 140 W RMS x 8 @ 14.4 V input - 2 Ohm < 1% THD
- Total rated power output (Watts): 280 W RMS x 4 @ 14.4 V input - 4 Ohm Bridged < 1% THD
- Frequency response: 10 Hz - 40 kHz (-3dB, dB @ 4 Ohm rated power)
- Input sensitivity: 0.3 V - 8 V RMS (user adjustable)
- Input impedance: 7k Ohm nominal
- High-pass/low-pass full range filter: yes (user selectable)
- HP variable crossover frequency: 32 Hz - 320 Hz
- LP variable crossover frequency: 32 Hz - 320 Hz
- Bass boost: 0 dB - 9 dB, user adjustable (zone 3 only)
- Operating voltage: 10.8 V - 16 V DC
- Current consumption (StandBy): < 1 mA @ 14.4 V input
- Current consumption (Idle): < 2.5 A @ 14.4 V input
- Current consumption (Max): 100 A
- Fuse rating: 4 x 40 A ATC blade-type (SAE J1171 compliant)
- Operating temperature range: 32° to 122° F (0° to 50° C)
