Specification
General
- Physical Dimensions: 355 x 376.7 x 82.7 mm
- Display Size: 15" diagonal, (228.1 x 304.1 mm diagonal)
- Display Resolution: 1024 x 768 pixels
- Display Type: XGA
- Weight: 4.0 kg (6.0 kg with bail mount)
- Water Rating: IP26/IP27 (IEC60529)
- Power Supply: 10 to 36 VDC
- Power Consumption: 4 A (typical current draw @ 12 VDC) 6.5 A (Max. current draw @ 12 VDC)
- Antenna: External over BNC
- Mounting Options: Flat and flush, bail with optional accessory (Garmin does not offer any hardware or accessories for a flat-mount installation. Professional tools and knowledge are required.)
- Receiver: 10 Hz GPS/GLONASS/GALILEO/BEIDOU/QZSS/GAGAN AND SBAS
- Multi-languages support: English, Simplified Chinese, Traditional Chinese, Japanese, Korean, Thai, Indonesia Bahasa, Malaysia Bahasa, Vietnamese, Burmese, Hindi, Gujarat
Maps & Memory
- Preloaded Map: Worldwide basemap
- Bluechart compatibility: Yes
- Data Cards: 2 SD card slots; 32 GB Max. storage
- Waypoints: 5000
- Routes: 100
- Tracks: 50 saved tracks
Sonar Features & Specifications
- Frequencies Supported: Traditional: 50/77/200
Dual Channel CHIRP: 28-210
SideVü/ClearVü: CHIRP 260/455/800
(dependent on transducer)
- Transmit Power: 1 kW traditional; 1 kW CHIRP; 500 W SideVü/ClearVü
- Maximum Depth: 5,000 ft (1,500 m) at 1kW (Freshwater)
- Dual -Frequency (50/200KHZ) Capable
- Dual -Beam (77/200KHZ) Sonar Capable
- CHIRP Sonar Technology: Built in
- CLEARVÜ
- SIDEVÜ
- Bottom Lock (Shows return from the bottom up)
- Water Temperature Log and Graph
- Sonar Recording
- Sonar History Rewind
- GSD Blackbox Sonar Support
- Quickdraw Contours
Connections
- NMEA 2000 Compatible
- NMEA 0183 Compatible
- Transducer Pin Number: 12pin * 1
- GSD Sonar
- GPS Antenna
