Specifications
- Physical dimensions without bracket (LxWxH): 14.13" x 7.06" x 1.75" (359 x 180 x 45 mm)
- Physical dimensions with bracket (LxWxH) : 14.13" x 7.06" x 2.13" (359 x 180 x 50 mm)
- Weight: 6.94 lb (3.15 kg)
- Water Rating: IPX2
- Amplifier class: Class-D
- CEA-2006 power rating: 150 watt RMS x 8 @ 14.4 V input - 4 ohm < 1% THD
- Total rated power output - 2 ohm (watts): 290 watt RMS x 8 @ 14.4 V input - 2 ohm < 1% THD
- Total rated power output - 4 ohm Bridged (watts): 580 watt RMS x 4 @ 14.4 V input - 4 ohm Bridged < 1% THD
- Peak power (watts): 2400 watts
- Input sensitivity: 1.6 V RMS
- Input impedance: 22k ohm
- Operating voltage: 10.8 V - 16 V DC
- Current draw, in standby/off using amplifier on wire: < 5 mA @ 14.4 V input
- Current draw, on, no audio: < 1.60 A @ 14.4 V input
- Fuse rating: 125 A electronic fuse (no replacement neccessary)
- Power-cable fuse model and rating: Bussmann™ BK/AMI-030 30 A fast-acting
- Ignition Safety Protected (SAE J1171): Yes
- Protection circuits: Reverse voltage/Input under/over voltage/Over temperature/Output short circuit
- Operating temperature range: 32° to 122° F (0° to 50° C)
