Specifications
General
- Dimension: 7.6" x 5.5" x 2.9" (19.2 x 14.0 x 7.4 cm)
- Weight: 2.8 lbs (1.3 kg)
- Water Rating: IPX7
- Touchscreen: Yes
- Display Type: WSVGA
- Display Size: 6.1" x 3.5"; 7.0" diagonal (15.4 x 9.1 cm; 17.8 cm diagonal)
- Display resolution: 1024 x 600 pixels
- Mounting Options: Bail, flush or flat (Garmin does not offer any hardware or accessories for a flat-mount installation. Professional tools and knowledge is required.)
- Input: Touchscreen
Maps & Memory
- Accepts Data Cards: 2 microSD cards (back of unit)
- Waypoints: 5000
- Track points: 50,000
- Tracks: 50 saved tracks
- Navigation Routes: 100
Sensors
- GPS: Yes
- GLONASS : Yes
- Galileo : Yes
- Has built-in receiver: Yes
- Receiver: 10 Hz
- NMEA 2000 Compatible: Yes
- NMEA 0183 Compatible: Yes
- Supports WAAS: Yes
Optional Map Support
- BlueChart g3
- BlueChart g3 Vision
- LakeVü g3
- LakeVü g3 Ultra
- Garmin Navionics+™
- Garmin Navionics Vision+™
- TOPO 100K
- Standard Mapping
- Garmin Quickdraw Contours
- Raster chart support
ChartPlotter Features
- Smart Mode Compatible
- AIS
- DSC
- Supports Fusion-Link™ compatible radios
- GSD Black Box Sonar Support
- GCV Black Box Sonar Support
- ActiveCaptain® compatible
- GRID (Garmin Remote Input Device) compatible
- Wireless Remote Compatible
- Sailing Features
- Spoken audio alerts
- OneHelm support
Electrical Features
- Power Input: 10 to 32 Vdc
- Typical current draw at 12 Vdc: 1.18 A
- Maximum current draw at 12 Vdc: 2.96 A
- Maximum power usage at 10 Vdc: 35.9W
Sonar Features
- Display Sonar: Yes
- Power output: 1 kW
- Traditional sonar (dual frequency/beam): built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP)
- ClearVü: Built-in 260/455/800/1000/1200 kHz
- SideVü: Built-in 260/455/800/1000/1200 kHz
Connactions
- NMEA 2000® ports: 1
- NMEA 0183 Input (Rx) Ports: 1
- NMEA 0183 output (Tx) ports: 1
- Garmin Marine Network Ports: 1
- Video input ports: 1 (BNC composite)
- J1939 ports: 1
- 12-pin transducer ports: 1
- USB ports: Yes
- BLUETOOTH® pairing: Yes
- ANT+ (Connectivity): Yes
- Garmin Wi-Fi network (local connection): Yes
