Specifications
General
- Dimension: 9.2" x 6.4" x 3" (23.3 x 16.2 x 7.6 cm)
- Weight: 3.6 lbs (1.6 kg)
- Water Rating: IPX7
- Touchscreen: Yes
- Display Type: WXGA
- Display Size: 7.8" x 4.4"; 9.0" diagonal (19.9 cm x 11.2 cm; 22.9 cm diagonal)
- Display resolution: 1280 x 720 pixels
- Mounting Options: Bail, flush or flat (Garmin does not offer any hardware or accessories for a flat-mount installation. Professional tools and knowledge is required.)
- Input: Touchscreen
Maps & Memory
- Accepts Data Cards: 2 microSD cards (back of unit)
- Waypoints: 5000
- Track points: 50,000
- Tracks: 50 saved tracks
- Navigation Routes: 100
Sensors
- GPS: Yes
- GLONASS: Yes
- Galileo: Yes
- Has built-in receiver: Yes
- Receiver: 10 Hz
- NMEA 2000 Compatible: Yes
- NMEA 0183 Compatible: Yes
- Supports WAAS: Yes
Optional Map Support
- BlueChart g3
- BlueChart g3 Vision
- LakeVü g3
- LakeVü g3 Ultra
- Garmin Navionics+™
- Garmin Navionics Vision+™
- TOPO 100K
- Standard Mapping
- Garmin Quickdraw Contours
ChartPlotter Features
- Smart Mode Compatible
- AIS
- DSC
- Supports Fusion-Link™ compatible radios
- GSD Black Box Sonar Support
- GCV Black Box Sonar Support
- ActiveCaptain® compatible
- GRID (Garmin Remote Input Device) compatible
- Spoken audio alerts
- Wireless Remote Compatible
- Sailing Features
- OneHelm support
Electrical Features
- Power Input: 10 to 32 Vdc
- Typical current draw at 12 Vdc: 1.37 A
- Maximum current draw at 12 Vdc: 3.20 A
- Maximum power usage at 10 Vdc: 40.2W
Sonar Features
- Display Sonar: Yes
- Power output: 1 kW
- Traditional sonar (dual frequency/beam): Built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP)
- ClearVü: Built-in 260/455/800/1000/1200 kHz
- SideVü: Built-in 260/455/800/1000/1200 kHz
Connactions
- NMEA 2000® ports: 1
- NMEA 0183 Input (Rx) Ports: 1
- NMEA 0183 output (Tx) ports: 1
- Video input ports: 1 (BNC composite)
- J1939 ports: 1
- Garmin Marine Network Ports: 1
- 12-pin transducer ports: 1
- USB ports: Yes
- BLUETOOTH® pairing: Yes
- ANT+ (Connectivity): Yes
- Garmin Wi-Fi network (local connection): Yes
