Specifications
General
- Dimension: 9.3” x 5.5” x 2.3” (23.5 x 14.0 x 5.8 cm)
- Weight: 1.7 lbs (0.77 kg)
- Water Rating: IPX7
- Touchscreen: Yes
- Display Type: WVGA color
- Display Size: 3.4" x 6.1" (8.6 x 15.4 cm); 7.0" diag (17.8 cm)
- Display resolution: 800 x 480 pixels
- Mounting Options: flush, tilt/swivel
- Input: Keyed
Maps & Memory
- Waypoints/favorites/locations: 5000
- Track points: 50,000
- Tracks: 50
- Navigation Routes: 100
Sensors
- GPS: Yes
- Has built-in receiver: Yes
- Supports WAAS: Yes
Electrical Features
- Power Input: 12 to 20 Vdc
- Typical current draw : 0.55 A
- Max current draw : 1.5 A
- Power Consumption : 6.6
Sonar Features
- Display Sonar: Yes
- Traditional sonar (dual frequency/beam): Built-in
- ClearVü: Yes
- Frequency: Traditional: 50/77/200 kHz
CHIRP (mid and high)
ClearVü 260/455/800 kHz
- Transmit power: 500 W (RMS)
- Bottom Lock (shows return from the bottom up): Yes
- Water temperature log: Yes
Connections
- 4-pin transducer ports: 1
- Garmin Wi-Fi network (local connection): Yes
Fishfinder Features
- Split-screen zoom
- Fish Symbol ID (helps identify fish targets)
- Autogain technology (minimizes clutter; maximizes targets)
- Adjustable depth line (measures depth of underwater objects)
- A-scope (real time display of fish passing through transducer beam)
- Water temperature sensor included
- Depth range shading
