Specifications
General
- Dimension: 11.4" x 6.5" x 2.4" (26.3 x 16.5 x 6.5 cm)
- Weight: 2.3 lbs (1.0 kg)
- Water Rating: IPX7
- Touchscreen: Yes
- Display Type: WVGA, NP
- Display Size: 7.8" x 4.8"; 9" diagonal (19.9 x 11.3 cm; 22.9 cm diagonal)
- Display resolution: 800 x 480 pixels
- Mounting Options: Bail or Flush
- Input: Touchscreen with Keyed Assist
Maps & Memory
- Accepts Data Cards: 1 microSD card; 32 GB maximum size
- Waypoints: 5000
- Track points: 50,000
- Tracks: 50 saved tracks
- Navigation Routes: 100
Sensors
- GPS: Yes
- Has built-in receiver: Yes
- Receiver: 5Hz
- NMEA 2000 Compatible: Yes
- NMEA 0183 Compatible: Yes
- Supports WAAS: Yes
Optional Map Support
- BlueChart g3
- BlueChart g3 Vision
- LakeVü g3
- LakeVü g3 Ultra
- Garmin Navionics+™
- Garmin Navionics Vision+™
- TOPO 100K
- Standard Mapping
- Garmin Quickdraw Contours
ChartPlotter Features
- AIS
- DSC
- Supports Fusion-Link™ compatible radios
- ActiveCaptain® compatible
- Wireless Remote Compatible
- Sailing Features
Electrical Features
- Power Input: 9 to 18 Vdc
- Typical current draw at 12 Vdc: 1.0 A
- Maximum current draw at 12 Vdc: 1.5 A
- Maximum power usage at 10 Vdc: 18W
Sonar Features
- Display Sonar: Yes
- Power output: 500 W
- Traditional sonar (dual frequency/beam): Built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP)
- ClearVü: Built-in 260/455/800/1000/1200 kHz
- SideVü: Built-in 260/455/800/1000/1200 kHz
Connactions
- NMEA 2000® ports: 1
- NMEA 0183 Input (Rx) Ports: 1
- NMEA 0183 output (Tx) ports: 1
- Garmin Marine Network Ports: 1 Panoptix™ port
- 12-pin transducer ports: 1
